Sale!
Turning Insert: MABR3020 1025, Carbide
Original price was: 74,00 $.54,99 $Current price is: 54,99 $.
Specifications
| Insert Style: MABR | ANSI Size Code: 3020 |
| ISO Size Code: 3020 | Insert Shape: Non-ISO Specialty Shapes |
| Inscribed Circle (Decimal Inch): 0.1250 | Inscribed Circle (Inch): 1/8 |
| Inscribed Circle (mm): 3.17 | Corner Radius (mm): 0.20 |
| Corner Radius (Decimal Inch): 0.0079 | Insert Material: Carbide |
| Manufacturer Grade: 1025 | Coating/Finish: TiN; TiAlN |
| Relief Angle: 6.000 | Insert Thickness (Inch): 1/8 |
| Insert Thickness (Decimal Inch): 0.1250 | Insert Thickness: 3.17 |
| Insert Hand: Right Hand | Series: CoroCut XS |
| Chip Breaker Operation: None | Grade Characteristics: Stainless Steel (M) – High Wear-Resistance to Moderate Wear-Resistance and Toughness; Steel (P) – High Wear-Resistance to Moderate Wear-Resistance and Toughness |
| Side Clearance: Positive | Hole Diameter (Decimal Inch): 0.1250 |
| ANSI Insert Code: MABR3020 | ISO Insert Code: MABR3020 |
| Insert Holding Method: Screw | Coating Process: PVD |
| Primary Workpiece Material Code: P; M | Iso Code: MABR 3 020 1025 |
| Manufacturers Catalog Number: MABR 3 020 1025 | Multi-Use Tool: Yes |
| Full Radius: Yes | Multi-Use Application: Turning |
| UNSPSC Code: 23242105 | Country of Origin: Japan |
| Insert Style: MABR | |
| ANSI Size Code: 3020 | |
| ISO Size Code: 3020 | |
| Insert Shape: Non-ISO Specialty Shapes | |
| Inscribed Circle (Decimal Inch): 0.1250 | |
| Inscribed Circle (Inch): 1/8 | |
| Inscribed Circle (mm): 3.17 | |
| Corner Radius (mm): 0.20 | |
| Corner Radius (Decimal Inch): 0.0079 | |
| Insert Material: Carbide | |
| Manufacturer Grade: 1025 | |
| Coating/Finish: TiN; TiAlN | |
| Relief Angle: 6.000 | |
| Insert Thickness (Inch): 1/8 | |
| Insert Thickness (Decimal Inch): 0.1250 | |
| Insert Thickness: 3.17 | |
| Insert Hand: Right Hand | |
| Series: CoroCut XS | |
| Chip Breaker Operation: None | |
| Grade Characteristics: Stainless Steel (M) – High Wear-Resistance to Moderate Wear-Resistance and Toughness; Steel (P) – High Wear-Resistance to Moderate Wear-Resistance and Toughness | |
| Side Clearance: Positive | |
| Hole Diameter (Decimal Inch): 0.1250 | |
| ANSI Insert Code: MABR3020 | |
| ISO Insert Code: MABR3020 | |
| Insert Holding Method: Screw | |
| Coating Process: PVD | |
| Primary Workpiece Material Code: P; M | |
| Iso Code: MABR 3 020 1025 | |
| Manufacturers Catalog Number: MABR 3 020 1025 | |
| Multi-Use Tool: Yes | |
| Full Radius: Yes | |
| Multi-Use Application: Turning | |
| UNSPSC Code: 23242105 | |
| Country of Origin: Japan |
| MSC# | 42974741 |
| Mfr# | 5733331 |
