Turning Insert: CNMG432ESU AC520U, Carbide
Original price was: 14,00 $.9,99 $Current price is: 9,99 $.
Specifications
| Insert Style: CNMG | ANSI Size Code: 432 |
| ISO Size Code: 120408 | Insert Shape: C – Diamond (Rhombic) 80-Deg |
| Included Angle: 80.00 | Inscribed Circle (Decimal Inch): 0.5000 |
| Inscribed Circle (Inch): 1/2 | Corner Radius (Inch): 1/32 |
| Corner Radius (Decimal Inch): 0.0313 | Insert Material: Carbide |
| Manufacturer Grade: AC520U | Coating/Finish: AlCrN; TiAlN |
| Relief Angle: 0.000 | Insert Thickness (Inch): 3/16 |
| Insert Thickness (Decimal Inch): 0.1875 | Insert Hand: Neutral |
| Series: CN | Chip Breaker Operation: Light Machining; Finishing |
| Grade Characteristics: Special, Super Alloys (S) – High Wear-Resistance to Moderate Wear-Resistance and Toughness; Stainless Steel (M) – Moderate Wear-Resistance and Toughness | Side Clearance: Negative |
| Hole Diameter (Decimal Inch): 0.2031 | ANSI Insert Code: CNMG432 |
| ISO Insert Code: CNMG120408 | Insert Holding Method: Pin; Clamp |
| Clearance Code: N | Tolerance Code: M |
| Coating Process: PVD | Rake: Positive |
| Insert Length (Decimal Inch): 0.5079 | Primary Workpiece Material Code: S; M |
| Secondary Workpiece Material: Superalloy; Stainless Steel | Secondary Workpiece Material Code: S; M |
| Iso Code: CNMG120408N-SU | Standards: ISO 13399; ANSI |
| Proprietary Coating Designation: Super ZX | Chip Breaker: ESU |
| Rake Angle: 13 | UNSPSC Code: 23242105 |
| Country of Origin: Japan | |
| Insert Style: CNMG | |
| ANSI Size Code: 432 | |
| ISO Size Code: 120408 | |
| Insert Shape: C – Diamond (Rhombic) 80-Deg | |
| Included Angle: 80.00 | |
| Inscribed Circle (Decimal Inch): 0.5000 | |
| Inscribed Circle (Inch): 1/2 | |
| Corner Radius (Inch): 1/32 | |
| Corner Radius (Decimal Inch): 0.0313 | |
| Insert Material: Carbide | |
| Manufacturer Grade: AC520U | |
| Coating/Finish: AlCrN; TiAlN | |
| Relief Angle: 0.000 | |
| Insert Thickness (Inch): 3/16 | |
| Insert Thickness (Decimal Inch): 0.1875 | |
| Insert Hand: Neutral | |
| Series: CN | |
| Chip Breaker Operation: Light Machining; Finishing | |
| Grade Characteristics: Special, Super Alloys (S) – High Wear-Resistance to Moderate Wear-Resistance and Toughness; Stainless Steel (M) – Moderate Wear-Resistance and Toughness | |
| Side Clearance: Negative | |
| Hole Diameter (Decimal Inch): 0.2031 | |
| ANSI Insert Code: CNMG432 | |
| ISO Insert Code: CNMG120408 | |
| Insert Holding Method: Pin; Clamp | |
| Clearance Code: N | |
| Tolerance Code: M | |
| Coating Process: PVD | |
| Rake: Positive | |
| Insert Length (Decimal Inch): 0.5079 | |
| Primary Workpiece Material Code: S; M | |
| Secondary Workpiece Material: Superalloy; Stainless Steel | |
| Secondary Workpiece Material Code: S; M | |
| Iso Code: CNMG120408N-SU | |
| Standards: ISO 13399; ANSI | |
| Proprietary Coating Designation: Super ZX | |
| Chip Breaker: ESU | |
| Rake Angle: 13 | |
| UNSPSC Code: 23242105 | |
| Country of Origin: Japan |
| MSC# | 41204306 |
| Mfr# | 19HWAPA |
