Standard Knurl Wheel: 1″ Dia, 90 ° Tooth Angle, 12 TPI, Straight, Cobalt

48,99 $

SKU: SKUyt8HN3DGe9 Categories: Knurling Tools, Shop All Products, Turning & Boring Tag: Dorian Tool Brand: Dorian Tool

Description
Reviews (0)

Specifications

Knurl Shape: Standard	Tooth Pattern: Straight
Pattern: Straight	Form Or Cut Type: Form
Material: Cobalt	Knurl Diameter (mm): 25.40
Knurl Diameter (Decimal Inch): 1.0000	Knurl Diameter (Inch): 1
Face Width (Decimal Inch): 0.2360	Hole Diameter (Inch): 5/16
Hole Diameter (Decimal Inch): 0.3125	Pitch (TPI): 12
Pitch System: Circular	Pitch (mm): 2.00
Included Tooth Angle: 90	Finish: Titanium Nitride
Pitch Type: Coarse	Knurl Series: M
UNSPSC Code: 23242118	Country of Origin: UNITED STATES
Knurl Shape: Standard
Tooth Pattern: Straight
Pattern: Straight
Form Or Cut Type: Form
Material: Cobalt
Knurl Diameter (mm): 25.40
Knurl Diameter (Decimal Inch): 1.0000
Knurl Diameter (Inch): 1
Face Width (Decimal Inch): 0.2360
Hole Diameter (Inch): 5/16
Hole Diameter (Decimal Inch): 0.3125
Pitch (TPI): 12
Pitch System: Circular
Pitch (mm): 2.00
Included Tooth Angle: 90
Finish: Titanium Nitride
Pitch Type: Coarse
Knurl Series: M
UNSPSC Code: 23242118
Country of Origin: UNITED STATES
