Spiral Flute Tap: 1/4-20, UNC, 3 Flute, Modified Bottoming Chamfer, 2B/3B Class of Fit, Cobalt, Oxide Finish
Original price was: 29,00 $.21,89 $Current price is: 21,89 $.
Specifications
| Thread Size (Inch): 1/4-20 | Thread Standard: UNC |
| Chamfer: Modified Bottoming | Material: Cobalt |
| Class Of Fit: 2B/3B | Coating/Finish: Oxide |
| Thread Direction: Right Hand | Coolant Through: No |
| Material Application: Non-Ferrous Metal; Stainless Steel; Cast Iron; Steel | Number Of Flutes: 3 |
| Flute Direction: Right Hand | Helix Angle: 38.00 |
| Proprietary Coating/Finish: NE2 | Oversize: No |
| Primary Workpiece Material: Aluminum & Non-Ferrous; Stainless Steel; Steel | Threads per Inch: 20 |
| Thread Length (Decimal Inch): 0.6690 | Overall Length (Decimal Inch): 3.1500 |
| Application: Blind Hole Threading | Primary Workpiece Material Code: P; M; N |
| Shank Diameter (Decimal Inch): 0.2550 | Tapping Depth (Decimal Inch): 1.1810 |
| Square Size (Decimal Inch): 0.1910 | Flute Style: Medium |
| Series: Enorm | UNSPSC Code: 23241600 |
| Product Name: Emuge MultiTAP 0550 | Country of Origin: Germany |
| Thread Size (Inch): 1/4-20 | |
| Thread Standard: UNC | |
| Chamfer: Modified Bottoming | |
| Material: Cobalt | |
| Class Of Fit: 2B/3B | |
| Coating/Finish: Oxide | |
| Thread Direction: Right Hand | |
| Coolant Through: No | |
| Material Application: Non-Ferrous Metal; Stainless Steel; Cast Iron; Steel | |
| Number Of Flutes: 3 | |
| Flute Direction: Right Hand | |
| Helix Angle: 38.00 | |
| Proprietary Coating/Finish: NE2 | |
| Oversize: No | |
| Primary Workpiece Material: Aluminum & Non-Ferrous; Stainless Steel; Steel | |
| Threads per Inch: 20 | |
| Thread Length (Decimal Inch): 0.6690 | |
| Overall Length (Decimal Inch): 3.1500 | |
| Application: Blind Hole Threading | |
| Primary Workpiece Material Code: P; M; N | |
| Shank Diameter (Decimal Inch): 0.2550 | |
| Tapping Depth (Decimal Inch): 1.1810 | |
| Square Size (Decimal Inch): 0.1910 | |
| Flute Style: Medium | |
| Series: Enorm | |
| UNSPSC Code: 23241600 | |
| Product Name: Emuge MultiTAP 0550 | |
| Country of Origin: Germany |
| MSC# | 67073734 |
| Mfr# | BU533200.5009 |
| Big Book# | 347 |
