Replaceable Tip Milling Shank: Series Multimaster, 25 mm Projection
Original price was: 219,00 $.138,89 $Current price is: 138,89 $.
Specifications
| Shank Type: Collet | Shank Taper Size: ER32 |
| Neck Thread Size: T10 | Overall Length (Decimal Inch): 2.7400 |
| Overall Length (mm): 69.60 | Shank Shape: Conical |
| Tool Material: Solid Carbide | Neck Diameter (mm): 15.30 |
| Coolant Through: Yes | Toolholder Style: MM S-ER |
| Series: Multimaster | Head Length (mm): 25.00 |
| Head Length (Decimal Inch): 0.9800 | Tool Application: Milling |
| Weldon Flat: No | Effective Length (mm): 25.00 |
| Effective Length (Decimal Inch): 0.9843 | Milling Tip Style: HM90 E90A-MM-10; MM HCR; MM HCD; MM HBR; HCM-MM; E93CN-MM; MM EB; MM EC-4; HCE-MM; HP E90AN-MM-07 |
| Projection (mm): 25.00 | UNSPSC Code: 23291600 |
| Country of Origin: Israel | |
| Shank Type: Collet | |
| Shank Taper Size: ER32 | |
| Neck Thread Size: T10 | |
| Overall Length (Decimal Inch): 2.7400 | |
| Overall Length (mm): 69.60 | |
| Shank Shape: Conical | |
| Tool Material: Solid Carbide | |
| Neck Diameter (mm): 15.30 | |
| Coolant Through: Yes | |
| Toolholder Style: MM S-ER | |
| Series: Multimaster | |
| Head Length (mm): 25.00 | |
| Head Length (Decimal Inch): 0.9800 | |
| Tool Application: Milling | |
| Weldon Flat: No | |
| Effective Length (mm): 25.00 | |
| Effective Length (Decimal Inch): 0.9843 | |
| Milling Tip Style: HM90 E90A-MM-10; MM HCR; MM HCD; MM HBR; HCM-MM; E93CN-MM; MM EB; MM EC-4; HCE-MM; HP E90AN-MM-07 | |
| Projection (mm): 25.00 | |
| UNSPSC Code: 23291600 | |
| Country of Origin: Israel |
| MSC# | 45389582 |
| Mfr# | 3105839 |
