Replaceable-Tip Drill: 0.433 to 0.449" Dia, 2.16" Max Depth, 5/8" Straight-Cylindrical Shank

Replaceable-Tip Drill: 0.433 to 0.449″ Dia, 2.16″ Max Depth, 5/8″ Straight-Cylindrical Shank

Original price was: 320,00 $.Current price is: 122,99 $.

SKU: SKUo2HVvIS7Ka Categories: Indexable Cutting Tools, Indexable Holemaking, Shop All Products Tag: Iscar Brand: Iscar

Description
Reviews (0)

Specifications

Minimum Drill Diameter (Decimal Inch): 0.4330	Maximum Drill Diameter (Decimal Inch): 0.4490
Drill Depth by Diameter Ratio: 5xD	Maximum Drill Depth (Decimal Inch): 2.1600
Shank Type: Straight-Cylindrical	Shank Diameter (Inch): 5/8
Shank Diameter (Decimal Inch): 0.6250	Insert Seat Size: 11
Compatible Insert Style: ICK; iCP-2M; FCP; ICM; ICK-2M; ICN; ICP	Overall Length (Decimal Inch): 4.7100
Series: SumoCham	Toolholder Style: DCN
Standards: ISO 13399	Coolant Through: Yes
UNSPSC Code: 23291502	Country of Origin: Israel
Minimum Drill Diameter (Decimal Inch): 0.4330
Maximum Drill Diameter (Decimal Inch): 0.4490
Drill Depth by Diameter Ratio: 5xD
Maximum Drill Depth (Decimal Inch): 2.1600
Shank Type: Straight-Cylindrical
Shank Diameter (Inch): 5/8
Shank Diameter (Decimal Inch): 0.6250
Insert Seat Size: 11
Compatible Insert Style: ICK; iCP-2M; FCP; ICM; ICK-2M; ICN; ICP
Overall Length (Decimal Inch): 4.7100
Series: SumoCham
Toolholder Style: DCN
Standards: ISO 13399
Coolant Through: Yes
UNSPSC Code: 23291502
Country of Origin: Israel
