Replaceable Drill Tip: KSEM0563HPG KC7315, 0.5626″ Dia, 14.29 mm Dia, 140 deg Point
109,99 $
Specifications
| Cutting Diameter (Decimal Inch): 0.5626 | Cutting Diameter (mm): 14.29 |
| Tip Material: Solid Carbide | Manufacturer Grade: KC7315 |
| Material Grade: Fine Grain | Series: KSEM |
| Coating Process: PVD | Insert Geometry: HPG |
| Insert Seat Size: B | Functional Length (Decimal Inch): 0.2815 |
| Primary Workpiece Material: Cast Iron; Steel | Primary Workpiece Material Code: P; K |
| Height (Decimal Inch): 0.2815 | Overall Length/Projection (Decimal Inch): 0.2815 |
| Drill Point Angle: 140 | Flute Type: Helical |
| Insert Holding Method: Clamp | ISO Number: KSEM0563HPG |
| Coolant Through: Yes | Flute Length (mm): 7.00 |
| Point Type: Standard | Spiral Type: Regular Spiral |
| Height (Inch): 9/32 | Style: KSEM |
| Applications: Drilling; ToolDimensions:2flute/2margin/coolant; ThroughCoolant:MQL(MinimumQuantityLubricant):Drilling; Drilling-ThroughCoolant; Drilling:InclinedExit; Drilling:StackedPlates | UNSPSC Code: 23242105 |
| Coating/Finish: TiAlN | Included Angle Degree: 140 |
| Number Of Flutes: 2 | Country of Origin: Germany |
| Cutting Diameter (Decimal Inch): 0.5626 | |
| Cutting Diameter (mm): 14.29 | |
| Tip Material: Solid Carbide | |
| Manufacturer Grade: KC7315 | |
| Material Grade: Fine Grain | |
| Series: KSEM | |
| Coating Process: PVD | |
| Insert Geometry: HPG | |
| Insert Seat Size: B | |
| Functional Length (Decimal Inch): 0.2815 | |
| Primary Workpiece Material: Cast Iron; Steel | |
| Primary Workpiece Material Code: P; K | |
| Height (Decimal Inch): 0.2815 | |
| Overall Length/Projection (Decimal Inch): 0.2815 | |
| Drill Point Angle: 140 | |
| Flute Type: Helical | |
| Insert Holding Method: Clamp | |
| ISO Number: KSEM0563HPG | |
| Coolant Through: Yes | |
| Flute Length (mm): 7.00 | |
| Point Type: Standard | |
| Spiral Type: Regular Spiral | |
| Height (Inch): 9/32 | |
| Style: KSEM | |
| Applications: Drilling; ToolDimensions:2flute/2margin/coolant; ThroughCoolant:MQL(MinimumQuantityLubricant):Drilling; Drilling-ThroughCoolant; Drilling:InclinedExit; Drilling:StackedPlates | |
| UNSPSC Code: 23242105 | |
| Coating/Finish: TiAlN | |
| Included Angle Degree: 140 | |
| Number Of Flutes: 2 | |
| Country of Origin: Germany |
| MSC# | 01326610 |
| Mfr# | 2499611 |
| Big Book# | 168 |
