Sale!

Indexable Turning Toolholder: Lever

Original price was: 338,00 $.Current price is: 138,99 $.

Specifications

Toolholder Style: PCLXR	Hand of Holder: Right Hand
Insert Compatibility: CX	Insert Holding Method: Lever
Shank Width (Inch): 1	Shank Height (Inch): 1
Overall Length (Decimal Inch): 6.0000	Rake: Positive
Cutting Direction: Right Hand	Compatible Insert Size Code: CXMG12T5
Rake Angle: 6	Multi-use Tool: No
Shank Width (Decimal Inch): 1.0000	Shank Height (Decimal Inch): 1.0000
Series: LOGIQ4TURN JETCUT	Cutting Tool Application: Turning
Head Length (Decimal Inch): 1.0000	Back of Bar to Cutting Edge (Inch): 1-1/4
Back of Bar to Cutting Edge (Decimal Inch): 1.2500	Standards: ISO 13399
Insert Inscribed Circle (Decimal Inch): 0.4920	Toolholder Material: Steel
UNSPSC Code: 23153308	Country of Origin: Israel
Toolholder Style: PCLXR
Hand of Holder: Right Hand
Insert Compatibility: CX
Insert Holding Method: Lever
Shank Width (Inch): 1
Shank Height (Inch): 1
Overall Length (Decimal Inch): 6.0000
Rake: Positive
Cutting Direction: Right Hand
Compatible Insert Size Code: CXMG12T5
Rake Angle: 6
Multi-use Tool: No
Shank Width (Decimal Inch): 1.0000
Shank Height (Decimal Inch): 1.0000
Series: LOGIQ4TURN JETCUT
Cutting Tool Application: Turning
Head Length (Decimal Inch): 1.0000
Back of Bar to Cutting Edge (Inch): 1-1/4
Back of Bar to Cutting Edge (Decimal Inch): 1.2500
Standards: ISO 13399
Insert Inscribed Circle (Decimal Inch): 0.4920
Toolholder Material: Steel
UNSPSC Code: 23153308
Country of Origin: Israel
