Indexable Turning Toolholder: Clamp & Pin

78,89 $

Specifications

Toolholder Style: MCLN	Hand of Holder: Right Hand
Insert Compatibility: CNMG 432	Insert Holding Method: Pin; Clamp
Shank Width (Inch): 3/4	Shank Height (Inch): 3/4
Coolant Through: No	Rake: Negative
Cutting Direction: Right Hand	Compatible Insert Size Code: CN43
Rake Angle: -5	Multi-use Tool: No
Series: Multi-Option	Overall Length (Inch): 4-1/2
Cutting Tool Application: Facing; Milling; Turning	Head Length (Decimal Inch): 1.0000
Back of Bar to Cutting Edge (Decimal Inch): 1.2500	Primary Workpiece Material: Universal
Primary Workpiece Material Code: P; S; H; K; M; N	Insert Inscribed Circle (Decimal Inch): 0.5000
Insert Inscribed Circle (Inch): 1/2	UNSPSC Code: 23153308
Insert Thickness (Decimal Inch): 0.1875	Country of Origin: Spain
Toolholder Style: MCLN
Hand of Holder: Right Hand
Insert Compatibility: CNMG 432
Insert Holding Method: Pin; Clamp
Shank Width (Inch): 3/4
Shank Height (Inch): 3/4
Coolant Through: No
Rake: Negative
Cutting Direction: Right Hand
Compatible Insert Size Code: CN43
Rake Angle: -5
Multi-use Tool: No
Series: Multi-Option
Overall Length (Inch): 4-1/2
Cutting Tool Application: Facing; Milling; Turning
Head Length (Decimal Inch): 1.0000
Back of Bar to Cutting Edge (Decimal Inch): 1.2500
Primary Workpiece Material: Universal
Primary Workpiece Material Code: P; S; H; K; M; N
Insert Inscribed Circle (Decimal Inch): 0.5000
Insert Inscribed Circle (Inch): 1/2
UNSPSC Code: 23153308
Insert Thickness (Decimal Inch): 0.1875
Country of Origin: Spain
