Indexable Square-Shoulder Face Mill: KJ5G-20R01, 2” Cut Dia, 0.7500″ Arbor Hole Dia, 0.4100″ Max Cutting Depth
138,99 $
Specifications
| Minimum Cutting Diameter (Decimal Inch): 2.0000 | Minimum Cutting Diameter (Inch): 2 |
| Minimum Cutting Diameter (mm): 50.80 | Maximum Cutting Diameter (Inch): 2 |
| Maximum Cutting Diameter (Decimal Inch): 2.0000 | Maximum Depth of Cut (Decimal Inch): 0.4100 |
| Arbor Hole Diameter (Inch): 3/4 | Arbor Hole Diameter (Decimal Inch): 0.7500 |
| Compatible Insert Size Code: 1005 | Cutter Style: KJ5G |
| Cutting Direction: Right Hand | Insert Holding Method: Screw |
| Lead Angle: 90 | Rake: Positive |
| Series: KJ5G | Maximum Ramping Angle: 1.5 |
| Overall Height (Decimal Inch): 1.5700 | Keyway Width (Inch): 5/16 |
| Keyway Width (Decimal Inch): 0.3120 | Pitch Type: Close |
| Tool Application: Facing; Ramping; Shouldering | Tool Performance: General Purpose |
| Primary Workpiece Material: Universal | Primary Workpiece Material Code: O |
| Cutting Edge Length (Decimal Inch): 0.4100 | Complete Insert Compatibility: THES1005… |
| UNSPSC Code: 27112803 | Toolholder Material: Steel |
| Manufacturers Catalog Number: KJ5G-20R01 | Coolant Through: Yes |
| Number Of Cutter Inserts: 5 | Number Of Flutes: 7 |
| Minimum Cutting Diameter (Decimal Inch): 2.0000 | |
| Minimum Cutting Diameter (Inch): 2 | |
| Minimum Cutting Diameter (mm): 50.80 | |
| Maximum Cutting Diameter (Inch): 2 | |
| Maximum Cutting Diameter (Decimal Inch): 2.0000 | |
| Maximum Depth of Cut (Decimal Inch): 0.4100 | |
| Arbor Hole Diameter (Inch): 3/4 | |
| Arbor Hole Diameter (Decimal Inch): 0.7500 | |
| Compatible Insert Size Code: 1005 | |
| Cutter Style: KJ5G | |
| Cutting Direction: Right Hand | |
| Insert Holding Method: Screw | |
| Lead Angle: 90 | |
| Rake: Positive | |
| Series: KJ5G | |
| Maximum Ramping Angle: 1.5 | |
| Overall Height (Decimal Inch): 1.5700 | |
| Keyway Width (Inch): 5/16 | |
| Keyway Width (Decimal Inch): 0.3120 | |
| Pitch Type: Close | |
| Tool Application: Facing; Ramping; Shouldering | |
| Tool Performance: General Purpose | |
| Primary Workpiece Material: Universal | |
| Primary Workpiece Material Code: O | |
| Cutting Edge Length (Decimal Inch): 0.4100 | |
| Complete Insert Compatibility: THES1005… | |
| UNSPSC Code: 27112803 | |
| Toolholder Material: Steel | |
| Manufacturers Catalog Number: KJ5G-20R01 | |
| Coolant Through: Yes | |
| Number Of Cutter Inserts: 5 | |
| Number Of Flutes: 7 |
| MSC# | 14083760 |
| Mfr# | 3031431 |
